Description
- (1) Heavy duty series wound motor delivers superior torque output and faster line speed.
- (2) 3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst condition.
- (3) Automatic,double cone brake.
- (4) Rotating ring gear clutch have the free spooling positioned actually for the rapid pay out of wire rope with ease.
- (5) Installation ,operation and maintenance with ease.
| Product Description: | ||
| Rated Line Pull: | 6000 lbs (2722kgs) | |
| Controls: |
Remote control and Line control
|
|
| Gear train: | Sealed, All-metal 3-stage planetary | |
| Motor: | DC 12V/24V 1.6kw/1.9hp Series Wound | |
|
Gear Ratio: |
307:1 | |
|
Cable: |
Φ7.2mm*24m | |
| Drum: | 2.52"/2.26" (64mm/134mm) | |
| Recommended Battery: | 650 CCA | |
|
Weight: |
24.5KG/25.5KG | |
|
Line speed and Motor current: |
||
|
Line pull LBS.<Kgs> |
line speed FPM.<MPM> |
Motor current Amp |
| 0<0> | 10.0<3.1> | 30 |
| 2000<907> | 7.5<2.3> | 120 |
| 4000<1814> | 4.9<1.5> | 210 |
| 6000<2722> | 2.9<0.9> | 320 |
| Line pull and cable capacity: | ||
| Layer of cable | Rated line Pull Lbs<Kgs> | Total Rope on Drmt Ft<M> |
| 1 | 6000<2722> | 13<4.0> |
| 2 | 4990<2265> | 29<9.0> |
| 3 | 4280<1940> | 48<14.6> |
| 4 | 3730<1690> | 69<21.0> |
| 5 | 3310<1500> | 79<24.0> |
